VMS 4x4
3DR : In-Dash Offroad GPS (Unit only, add suitable wiring loom set separately)
This product is just the unit, wiring loom set have to be bought seperately.
Features
3D Vector map
See the terrain in 3D while offroading and evaluate any track's gradient at a glance!
CAMPS11 POIs
Access free camping sites, Campgrounds, Caravan Parks, Hotels, Motels & more with CAMPS11 and CARAVAN PARK 6 POIs.
State Topo Maps included
State topogrpagical map bundle with NSW VIC QLD WA & Westprint maps preloaded
Single Navigation system
Single system that takes care of your both street and offroad navigation needs.
Apple Carplay & Android Auto
Apple Carplay and wired Android Auto are supported by 3DR for seamless ease and interaction while driving
Radio (AM / FM)
Listen to your favourite radio stations wether it is for listeing to music/talk shows or tune into emeregency radio broadcast
Reverse Camera Support
Never be unsure of your surroundings, such as walls, other vehicles and obstructions, uneven terrain etc while reversing their vehicle.
4G Support
Enjoy 4G speeds on your in-dash unit for music sreaming, video watch or just browsing with 4G SIM support.
Better accuracy
Pair text with an image to focus on your chosen product, collection, or blog post. Add details on availability, style, or even provide a review.
Inbuilt GPS supports multiple GNSS technologies like GLONASS, BEIDOU to provide accurate location and offline navigation.*Approx release date: 28th Nov 2022
The 3DR is designed to provide the best off-roading experience with functionality such as 3D Vector maps, tracklog recording, waypoints planting etc. It also comes with basic street navigation to provide user with directions to get out of the bush and back to the city/towns.
Current features include:
- 1.5 Din head unit with 10" Easy to use touch screen (will fit Double din spaces)
- Real-time 3D (Street and Offroad navigation)
- 3D vector maps with elevation profile to guide you through any terrain
-
Offline support with the in-built GPS
- Preloaded CAMPS11 Premium POIs with Caravan Park 6
- Display and overlay your favourite raster maps
- Navigation assistance on bush tracks - Spoken turn by turn directions on any track. *
- Track log (breadcrumb trail) recording
- Wireless Apple Carplay and wired Android Auto support
- Radio (AM/FM) support
- Play store access for downloading apps (Some apps will need internet to run)
- Steering wheel controls programming (Canbus vehicles require extra modules)
- Two-finger hold feature to instantly see distance between two points
- Reversing Camera support
- Traffic safety camera alerts NEW
* Provided the track is contiguous to the rest of the road network.
- VMS 3DR unit
- Power Looms
- USB Loom
Hardware |
|
| Unit Chasis dimensions (W*H) | 178 * 76 (in mm) |
| Display size | 10" diagonal (20.32 cm) |
| DIN size | 1.5 DIN |
| Display resolution | 1280*720 |
| Radio | ST7708 |
| Processor | UIS7862 Octa Core 1.8GHz |
| (8 cores 2*Cortex A75 +6*Cortex A55) | |
| USB Inputs | 3 x USB inputs |
| Operating System | Android 10 |
| Warranty | 12 months warranty on hardware |
System memory |
|
| Internal memory | 32GB |
| RAM | 3GB |
| Supported file formats | MP3/WMA/AAC/RM/FLAC/MPEG-1,2,4/H264/H263/VC1/RV/RMVB/DivX/JPEG/BMP/GIF/PNG |
Communication |
|
| Bluetooth | 5 |
| Wifi | 802.11 b/g/n |
| Network | 4G supported |
| Radio Function | AM Freq range: 522KHz - 1620KHz |
| FM Freq range: 87.5 MHz – 108.0 MHz | |
Connections |
|
| Video Input | Reversing Camera (12V triggered) AV video |
| Audio Input | AV in (Left/right) |
| Reverse Camera Input | Yellow RCA jack - composite vide |
| Reverse Camera Trigger | Reverse Camera will engage when vehicle is put into reverse gear. (providing the brown trigger wire is attched to the reversing light curcuit) |
